- The next generation of sound performance is here with the new R-Series Halo Preloaded Subwoofers featuring the new R-Series “R2” subwoofers for more accurate and authoritative bass.
- Unique ProLink Design – ProLink is unique to Alpine and allows you to link two R2-SB10V enclosures together using an optional KTX-H10 linking kit to create a dual subwoofer enclosure.
- Stand Out in the Crowd – Drawing inspiration from the sleek, tapered lines and clean silver finish of the Alpine Halo display, the R2-SB10V shares the same unique, curved edges outlined by a silver trim and a metallic front baffle for a matching system aesthetic.
- Improved Performance – The new R-Series subwoofers now feature larger, double-stacked magnets that contribute more motor force for deeper bass and tighter bass control compared to the previous generation.
With an ultra-shallow enclosure design and powerful sound output, the R-Series Shallow Preloaded Subwoofer Enclosures give you the best of both worlds in size and sound.
Features:
Optimal sealed cabinet quality
Aluminum Dust Cap
Neodymium Magnet
Alpine Gen2 DD Linear Magnetic Circuit
CARB compliant ¾” MDF construction
Premium Alpine embroidered black carpet
Alpine-branded terminal cup
Pre-installed steel mesh grille
Includes a 10” R-Shallow Subwoofer (RS-W10D4)
Rubber, modular stackable foot design
What's in the Box:
Sealed Cabinet with (1) 10” R-Series Shallow Subwoofer
Mounting Brackets
Owner’s Manual
Warranty Information
Online product registration information
Tech Specs:
Dimensions: 21.15” W x 5.25” H x 16” L
600W RMS Power Handling
Frequency response: 29Hz – 200Hz
Dual 4Ω voice coils wired in parallel for a 2Ω load (compatible with S-A60M or R-A75M)
Nominal Impedance: 2Ω
Voice Coil: 4”(101.6mm)
Designed for Tight Spaces
Now you don’t have to choose between bass and space! Alpine’s R-Series Shallow Preloaded Subwoofer Enclosure measures at a minimal 5.25” deep to deliver a loud and fun sound in most vehicle applications. Rubber “feet” are adjustable in height to accommodate uneven vehicle floors.
Extreme Output
Don’t let the size fool you – the enclosures feature the same motor movement (20MM of 1-way excursion) as the full-size R2-Series Subwoofers for extreme output in a shallow woofer design. At the heart of the R-Series Shallow Subwoofers is an oversized 4-inch voice coil that houses the lightweight and powerful neodymium magnet for 600W RMS of power handling.
- Product Dimensions : 24 x 17 x 9 inches; 32.65 Pounds
- Date First Available : December 29, 2022
- Manufacturer : Alpine
