Camera
Image Sensor:[Bullet channel]: 1/2.5" Progressive Scan CMOS; [PTZ channel]: 1/2.8" progressive scan CMOS
Max. Resolution:[Bullet channel] 3632 × 1632, [PTZ channel] 2560 × 1440
Min. Illumination:[Bullet channel]: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with light;[PTZ channel]: Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0.001 Lux @ (F1.6, AGC ON), 0 Lux with IR
Shutter Speed:1 s to 1/30,000 s
Day & Night:ICR
Zoom:[PTZ channel] 25 × optical, 16 × digital
Slow Shutter:yes

Lens
Focal Length:[Bullet channel]: 2.8 mm; [PTZ channel]: 4.8 to 120 mm, 25 × optical
FOV:[Bullet channel]: Horizontal field of view: 180±10°, Vertical field of view: 80±5°;[PTZ channel]:Horizontal field of view: 55° to 2.4° (wide-tele),Vertical field of view: 33° to 1.4° (wide-tele),Diagonal field of view: 61.5° to 2.8° (wide-tele)
Focus:semi-auto||manual||auto
Aperture:[Bullet channel]: F1.0; [PTZ channel]: F1.6
Zoom Speed:[PTZ channel]: approx. 3.6 s

Illuminator
Supplement Light Type:[PTZ channel]: IR; [Bullet channel]: White Light
Supplement Light Range;[PTZ channel]: up to 100 m; [Bullet channel]: up to 30 m
Smart Supplement Light:Yes

PTZ
Movement Range (Pan):360°
Movement Range (Tilt):-15° to 90° (auto flip)
Pan Speed:pan speed: configurable from 0.1° to 80°/s; preset speed: 80°/s
Tilt Speed:tilt speed: configurable from 0.1° to 80°/s, preset speed 80°/s
Proportional Pan:yes
Presets:300
Preset Freezing:yes
Patrol Scan:8 patrols, up to 32 presets for each patrol
Pattern Scan:4 pattern scans
Park Action:preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan
3D Positioning:yes
PTZ Status Display:yes
Scheduled Task:preset||pattern scan||patrol scan||auto scan||tilt scan||random scan||frame scan||panorama scan||dome reboot||dome adjust||aux output
Power-Off Memory:yes

Video
Video Compression:H.265||H.264||MJPEG
Video Bit Rate:32 kbps to 16384 kbps
H.264 Type:baseline profile||main profile||high profile
H.265 Type:main profile
Scalable Video Coding (SVC):H.264 and H.265 encoding
Region Of Interest (ROI):8 fixed regions for each stream

Audio
Audio Compression:G.711,G.722.1,G.726,MP2L2,PCM,AAC-LC,MP3
Audio Bit Rate:MP2L2: 16 kHz, 32 kHz, 48 kHz; AAC-LC: 16 kHz, 32 kHz, 48 kHz; PCM: 8 kHz, 16 kHz, 32 kHz, 48 kHz; MP3: 8 kHz, 16 kHz, 32 kHz, 48 kHz
Environment Noise Filtering:yes

Network
Protocols:IPv4/IPv6||HTTP||HTTPS||802.1x||Qos||FTP||SMTP||UPnP||SNMP||DNS||DDNS||NTP||RTSP||RTCP||RTP||TCP/IP||UDP||IGMP||ICMP||DHCP||PPPoE||Bonjour||WebSocket||WebSockets
Simultaneous Live View:20
API:ISAPI,SDK,ISUP,ON/VIF
User/Host:32
Security:Authenticated username and password||MAC address binding||HTTPS encryption||802.1X authenticated access||IP address filter
Network Storage:NAS (NFS, SMB/ CIFS)|| ANR
Client:iVMS-4200||Hik-Connect
Web Browser:IE11 ,Chrome57 ,Firefox52 ,Safari12 ,Edge79.0.309.65

Image Parameters Switch:Yes
Image Settings:sharpness, saturation, brightness, contrast Day/Night Switch:day, night, auto, scheduled-switch

Wide Dynamic Range (WDR):120 dB
SNR:≥ 52 dB
Defog:Digital defog
Image Stabilization:EIS
Image Enhancement:BLC,HLC,3D DNR
Privacy Mask:[Bullet channel] 8 programmable polygon privacy masks, [PTZ channel] 24 programmable polygon privacy masks; mask color or mosaic configurable
Regional Focus:Yes
Regional Exposure:Yes

Interface
Ethernet Interface:RJ45, self-adaptive 10M/100M Ethernet port
On-Board Storage:Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB
Audio:1 audio input, 2.0 to 2.4Vp-p, 1k Ohm±10%, 1 audio output, line level, impedance: 600 Ω
Alarm:1 alarm input, 1 alarm output
Reset:yes

Event
Basic Event:[PTZ channel] motion detection, video tampering alarm,[PTZ channel & bullet channel] alarm input and output, exception (IP address conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal Reboot)
Smart Event:[PTZ channel & bullet channel] audio exception detection,[PTZ channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection,[Bullet channel] line crossing detection, intrusion detection, region entrance detection, region exiting detection
Linkage:Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,audible warning,and PTZ actions (such as preset, patrol scan, pattern scan)
Smart Linkage:Panorama Linkage

Deep Learning Function
Face Capture:Detects up to 5 faces simultaneously, Supports detecting, tracking, capturing, grading, selecting of face in motion, and outputs the best face picture
Regional People Counting:Yes

General
Power:12VDC, PoE
Dimension: 6.5" × 14.7"
Weight:13.2 lb.
Material:ADC12
Operating Condition:-30℃ to 65℃ (-22°F to 149°F) ||humidity lower than 90%RH
General Function:mirror,watermark,password protection
Demist:Demist by heating the glass
Power Consumption And Current:Max. 24 W, including max. 2.6 W for heater and max. 11 W for supplement light
Protection:IP66 Standard, 6000 V Lightning Protection, Surge Protection and Voltage Transient Protection
